Product Description

This swing gate is a smart pedestrian channel management equipment developed, developed and produced by our company. It has beautiful appearance, mature technology and stable performance. The overall product shape is combined with the national standard 304 high-quality stainless steel and modern fine processing technology. It is sturdy and durable. It integrates mechanical, electronic, microprocessor control and various reading and writing technologies. The standard external electrical interface is intelligent and advanced. It is also convenient and practical, and can be freely docked with various smart devices.

1. Adopting national standard high quality 304 stainless steel, laser cutting, CNC planing groove bending, fine sanding texture, smooth appearance, elegant appearance, sturdy and durable

2, the use of automatic swing gate movement, smooth operation, soft buffer, low noise, with infrared in-position signal detection, can effectively control pedestrians orderly access

3, with automatic power-off function of power-off, automatic reset after power-on, meet fire and other special requirements, with good security

4. The system will automatically reset the gate when the gate is not open within the specified time after opening the gate to ensure the safety of the passage.

5, the unique mechanical transmission, microprocessor control and various reading and writing technologies are organically integrated into one, the effective card is opened after the card is swiped, and the pedestrian automatically resets after passing the infrared sensor

6. The swing gate runs smoothly and has low noise. It also has fault self-test and alarm prompt function, which is convenient for maintenance and use

It is suitable for one-way or two-way control of people's flow and import and export channels of electric vehicles and bicycles, such as government, schools, hospitals, banks, clubs, clubs, stations, terminals, enterprises and institutions, industrial parks, and residential areas.

Details

First, the main technical parameters

1. Appearance size: length 1200* width 300* height 980mm

2. Material structure: GB 304 stainless steel; 1.5mm face cover, 1.2mm side plate; frame structure

3, channel width: two sets of a split channel width of 1000mm

4, the length of the pendulum: the closed state exposed 480mm outside the chassis

5. Control mode: fully automatic

6, control direction: right hand one-way, left-hand one-way, two-way (optional)

7. Alarm anti-pinch: illegal intrusion, trailing alarm; mechanical and infrared sensing double anti-pinch to prevent bump; special occasions can be equipped with mechanical anti-collision function (manual reset)

8. Passing speed: 20 people/minute

9, working power: AC110V ~ AC220V

10, the use of the environment: indoor, outdoor (recommended awning); temperature: -30 ° C to 60 ° C; humidity: less than 95% RH, no condensation

11, communication method: TCP / IP or RS485

Second, feature features

1. It has a variety of working modes, which can be used for two-way card swiping in and out, and can be swiped on one side and the button on the other side.

2, the use of automatic swing gate movement, smooth operation, soft buffer, low noise, with infrared in-position signal detection, can effectively control pedestrians in an orderly access.

3, with mechanical anti-pinch and anti-collision function.

4, with automatic power-off function of power-off, automatic reset after power-on.

5. Unified and standard external electrical interface can be freely docked with various intelligent devices to facilitate system integration and remote control and management through management computer.

6, with super bright direction indicator, with clear traffic direction indication function, with an intuitive LED direction indicator to indicate whether it can pass or prohibit traffic.

7. With automatic reset function, it will automatically reset when it is not open within the specified time after opening the gate to ensure the safety of the channel.

Remarks: If you need to implement intelligent access control attendance and other functions, please install our company's access controller, card reader, fingerprint machine, face machine, barcode scanner and other equipment to achieve personnel access permissions settings, remote real-time monitoring, remote Open the door, view the entry and exit records, limit the number of time limit personnel management, regular open normally closed, anti-submarine back, fire alarm linkage, centralized management, attendance management, etc., please call or visit www.110365.com.

Three, scope of application

It is suitable for one-way or two-way control of people's flow and import and export channels of electric vehicles and bicycles, such as government, schools, hospitals, banks, clubs, clubs, stations, terminals, enterprises and institutions, industrial parks, and residential areas.
